Product Overview
The X519 (AF) is a spatial product for Afghanistan and dedicated to cost effective solutions for outdoor wireless networking applications.
It is flexible and ideal for point-to-point, point-to-multi point and outdoor Wi-Fi coverage applications.
Professional performance, coupled with user-friendly design, makes X519 (AF) an ideal choice for both business and home users.
| Channel Width | 1km | 2km | 6km | 10km | 15km |
| 20MHz | 200Mbps+ | 150Mbps+ | 100Mbps+ | 40Mbps+ | 10Mbps+ |
| * The above test data is obtained in coastal or remote areas where Wi-Fi Interference is relatively low. In actual use, it is recommended to have sufficient redundancy to ensure the actual performance. | |||||
| Model | X519 (AF) |
|
| CPU | Qualcomm Dual A53 @1.0 GHz |
|
| Operating Frequency | 5180-5825MHz (Spatial For Afghanistan) |
|
| Wireless Standards | Wi-Fi 6 |
|
| Channel Width | 20 MHz (Spatial For Afghanistan) |
|
| Proprietary Physical Layer | 2x2MU-MIMO/OFDMA based on 802.11ax underlying technology |
|
| Networking interface | 1*Gigabit |
|
| Transmit Power Range | Max 29dBm @20MHz |
|
| Antenna Frequency Range | 5.180-5.825GHz |
|
| Antenna Gain | 19dBi Dual Linear |
|
| Antenna Beam width | E:45°/ H:16° E:45°/ H:16° |
|
| LEDs | 1*Power, 1*SYS, 1*LAN, 3*Wi-Fi |
|
| Power Supply | PoE 22-56V |
|
| Power Consumption | <15W |
|
| Surge suppression | 8KV |
|
| Weatherproof Enclosure | IP67 |
|
| Size | 307*127*65mm |
|
| Weight | 0.8kg |
|
| Temperature | -30°C to 55°C |
|
| Working mode | AP WDS、 Client WDS |
|
| Network Mode | Bridge/Router |
|
| Firewall | Port Forwarding ,DMZ,ACL Filtering |
|
| Wireless Security | WPA-PSK,WPA2-PSK,WPA/WPA2-PSK,WPA2-PSK/WPA3-SAE,WPA3-SAE |
|
| VLAN | 802.1Q with 802.1p priority |
|
| DHCP | DHCP Server、 DHCP Client |
|
| Network Management | HTTP/HTTPS, SNMPv1/2, SNMPv3, TR069 |
|
| QoS (Quality of Service) | Three-level priority (voice, high, low) with packet classification by DSCP, COS, VLAN ID, IP & MAC Address, broadcast, multicast, and station priority |
|
| ARQ | yes |
|
| Nominal Receive Sensitivity (w/FEC) @20 MHz Channel |
MCS 0 = -95 dBm to MCS 11 (1024 QAM-5/6) = -64 dBm (per chain) |
MCS 0 = -95 dBm to MCS 11 (1024 QAM-5/6) = -64 dBm (per chain) |
| Modulation Levels (Adaptive) | MCS 0 (BPSK) to MCS 11(1024 QAM-5/6) | MCS 0 (BPSK) to MCS 11(1024 QAM-5/6) |
