| Features: Output power of 30W over four pairs Supports 10/100/1000/2500Base-T applications Plug-and-play installation Low power devices receive only the power they need |
 |
| Specifications: Input voltage：90 VAC to 264 VAC Input frequency：50 Hz to 60 Hz Inrush current：less than 75A at 230VAC cold start, 25° Output voltage：specified at 48V±5% Output current：will be performed from 625mA Meet green mode：<0.2W (at no load) Efficiency：75%-85% Holduptime：16ms typical at rated load and 115VAC Over voltage protection：latch off Short circuit protection：auto recovery Over current protection ：auto recovery |
Operating temperature ：-20℃ to 60℃ above 40℃, derate at 2.5% per degree Cooling ：free air convection Storage temperature ：20℃ to +85℃ EMI：FCC class "B" CISPR22 level "B" EMS ：EN61000-4-2, -3,-4,-5,-6,-11 Safety ：UL 60950-1,LPS CSA C22.2 No. 60950-1 TUV EN60950-1 |
